快速循环SLS 3 d打印机
QLS 230 is the most affordable open platform selective laser sintering (SLS) 3D printer for industrial use. It provides a 24 hour cycle speed using a single 30 Watt CO2 laser to produce prototypes with robust mechanical and thermal properties. In addition to a broad range of high-temp thermoplastic materials, it excels with recycled powders from HP®and EOS.
Increase Daily Output
With a cycle time of just 24 hours where the required cooling period is only 2 hours, the QLS 230 is a productivity powerhouse. It uses a single 30 Watt CO2 laser to increase your daily throughput without the need for a lengthy cooling period due to its smaller build chamber.
Material Flexibility
The QLS 230 is an open platform with 10+ qualified nylon and metal fusion materials. In addition to the currently qualified materials, it excels with recycled powders from HP and EOS for ultimate operational sustainability.
Lowest Total Cost of Ownership
With the lowest entry point in the professional selective laser sintering market, combined with lower operating costs due to its powder refresh rate of just 20% and use of third party materials, the QLS 230 offers the lowest total cost of ownership for your industrial SLS 3D printing needs.
NEW MATERIAL
Metal 3D Printing with ColdMetalFusion
Excited to announce our partnership with Headmade Materials and enable metal 3D printing capability via ColdMetalFusion on all of our SLS platforms!
With the addition of metals, the QLS series printers offer the most flexible, affordable, and scalable industrial SLS solution for both polymer and metal part production.
Specifications
| Technology | Selective Laser Sintering |
| Cycle Time | 24 hours |
| Build Volume | 230 x 230 x 230mm (9 x 9 x 9in) |
| Layer Thickness | 0.08 / 0.1 / 0.15 / 0.2mm |
| Build Speed | up to 20mm per hour |
| Accuracy | 0.2mm |
| Full Parameter Access | Yes |
| Laser Type | 1 x 30W CO2 |
| Printer Dimensions | 1,480 x 850 x 2,040mm (58.3 x 33.5 x 80.3in) |
Download Brochure
“我们ql 230 SLS打印机提供其他维的东西o not, the ability to use end-of-life powder from our EOS and HP MJF machines for high-quality SLS parts. On top of the operational sustainability, the smaller build volume of the QLS 230 allows for a 22 hour complete build cycle that only requires a 2 hour cooling cycle with zero negative effect on part accuracy or surface quality.
The adoption of the smaller platform for high daily throughput is a game changer. We have options for an expedited two business day turn-around in our 3D Printing Service.”
Oscar Klassen
CEO JawsTech
INTRODUCING
0% Interest Financing for Industrial 3D Printers.
Start printing now and pay over 36 months with 0% APR on approved credit. Offset upfront costs of hardware and put your capital back to work.
Ultimate Guide for SLS 3D Printing
Laser Sintering vs. Fusion Sintering—Which Powder Bed Fusion Technology is Best for You?
Download the full guide.
Open Material Platform
In addition to accepting recycled powder from HP and EOS, the QLS 230 currently has 10 qualified nylon powders, including a range of Polyamides, PP, PBT, TPU, as well as the patented metal powders from headmade materials®.
Intuitive Software
QLS 230 is powered by two advanced software suites, Buildware and XYZprint AMSLS. Buildware controls the sintering process while the XYZprint AMSLSallows users to start and monitor jobs remotely.
Cold Metal Fusion Compatible
Cold Metal Fusion by headmade materials®is a patented process that combines the advantages of fast cycle sintering with established powder metallurgy processes to create titanium and steel parts. Using a polymer-coated metal powder, the QLS 230 produces ‘green’ parts in a low temperature processing environment. Parts then go through a secondary debinding and sintering process that burns out any remaining polymer and sinters metal particles together to form final metal components.
